Introduction to Kymati KY-LOC 1D.01.01

The Kymati KY-LOC 1D.01.01 is a cutting-edge radar sensor designed for precise one-dimensional distance measurement and collision avoidance in various industrial settings. Developed by Kymati GmbH, this device leverages radar technology’s robustness to operate effectively under harsh weather conditions and in dusty environments, making it an ideal solution for heavy industries such as steel plants, container terminals, and open-pit mining.

Key Features of KY-LOC 1D.01.01

  1. Precise Distance Measurement: The KY-LOC 1D.01.01 offers reliable distance measurement between two radar sensors, with a detection range of 2 meters to 500 meters and a measurement range of up to 100 meters. The repeat accuracy is typically ±15 mm, and the absolute distance accuracy is ±50 mm.

  2. Adverse Weather Conditions: Unlike optical sensors, radar technology is not affected by weather conditions such as rain, snow, or fog, ensuring continuous operation regardless of the environment.

  3. Dust and Dirt Resistance: The device is highly reliable in dusty environments, which is particularly beneficial in industries where dust is prevalent, such as construction or mining.

  4. No Interference with WiFi or 5G: Operating on the 61 GHz band, the KY-LOC 1D.01.01 does not interfere with WiFi or 5G networks, ensuring seamless integration into existing communication systems.

  5. User-Defined Distance Warnings: Users can set preset distance warnings that trigger alerts when objects approach within specified thresholds. These warnings can be dynamically adjusted based on the approach speed, enhancing safety in fast-paced environments3.

  6. Maintenance-Free Operation: Once installed, the KY-LOC 1D.01.01 requires no maintenance, reducing downtime and operational costs. It is designed for both indoor and outdoor use, with an operating temperature range of -30°C to +75°C.

  7. Multiple Interface Options: The device supports Ethernet (100Base-Tx), PoE (802.3af), and RS485 interfaces, allowing for flexible integration into various control systems.

  8. Parallel Operation: Multiple KY-LOC pairs can operate simultaneously using different channel settings, making it suitable for complex industrial environments where multiple machines need to be monitored.

Applications of KY-LOC 1D.01.01

The versatility of the KY-LOC 1D.01.01 makes it applicable across several industries and scenarios:

  • Collision Avoidance in Heavy Industries: In environments like steel plants or container terminals, the KY-LOC 1D.01.01 helps prevent collisions between moving equipment such as cranes or transfer cars by creating no-go zones that dynamically adjust based on speed.

  • Railbound Machines: The sensor is particularly useful for railbound or straight-driving machines, ensuring precise distance measurement and control in rough production environments.

  • Free-Ranging Objects: It can also be used for monitoring free-ranging objects like rubber tire gantries, providing real-time distance data without requiring a fixed path.

Technical Specifications

Specification Description
Detection Range 2 m to 500 m
Measurement Range Up to 100 m
Repeat Accuracy ±15 mm
Absolute Distance Accuracy ±50 mm
Operating Frequency 61 GHz (ISM band)
Interfaces Ethernet (100Base-Tx), PoE (802.3af), RS485
Power Supply 9-36 V DC or PoE (802.3af)
Operating Temperature -30°C to +75°C
Protection Rating IP 66, IP66k, and IP68

Installation and Configuration

The installation of the KY-LOC 1D.01.01 involves mounting the sensors in a way that they face each other, with a minimum distance of 2 meters to ensure accuracy. The sensors can be configured to operate in various modes, including relay and remote configurations, allowing for flexible data transmission and reception.

Advantages Over Traditional Sensors

Compared to optical sensors or encoders, the KY-LOC 1D.01.01 offers several advantages:

  • Robustness in Harsh Environments: Radar technology is less susceptible to interference from dust, dirt, or weather conditions, making it more reliable in industrial settings.

  • No Line of Sight Required: Unlike optical sensors, radar can penetrate certain materials and does not require a clear line of sight, enhancing its versatility in complex environments.

  • Cost-Effectiveness: The maintenance-free operation and lack of interference issues reduce operational costs over time3.

Conclusion

The Kymati KY-LOC 1D.01.01 represents a significant advancement in industrial sensor technology, offering precise distance measurement and collision avoidance capabilities in challenging environments. Its robust design, flexibility, and reliability make it an essential tool for enhancing safety and efficiency in heavy industries. As industries continue to evolve and demand more sophisticated automation solutions, devices like the KY-LOC 1D.01.01 will play a critical role in shaping the future of industrial automation and safety systems.
